MTP/MPO Multimode OM1, OM2 Fiber Optic Patch Cable We supply MTP and MPO multimode fiber optic cables. Available configurations are Female to female or a male to male and male to female. Cable options include, Riser Rated Jacket, Plenum rated jacket, LSZH. Round cable, ribbon cable, or bare ribbon cable. The male version has MTP pins. Available in 4,8,12, 24, and 48 fiber array configurations. We use USConec MTP fiber optic connectors for all of our MTP and MPO terminations so that the highest performance is accomplished. Many additional options and combinations are available. All multi fiber optic cables are customizable. The MTP multimode connector is a mtp flat polished connector. There is a low loss version for multimode 62.5/125, or 50/125 at the customers request. |
|
- |
|
Pin Configuration |
|
UOM |
|
Length, 3 Digits |
|
Jacket Type |
|
Jacket Color |
|
Cable Type |
|
See Fiber Mode |
|
See Connector B |
|
See Connector A |
|
Product Group |
|
Fiber Count |
|
Toll Free (877)-320-3143 Call (321)-473-8933 |
|
MTP/MPO Specifications |
||||
|
|
MTP MM Elite |
MTP MM Standard |
MTP SM Elite |
MTP SM Standard |
|
Insertions Loss |
.10dB Typical .35dB Max Single Fiber |
.20dB Typical .60dB Max Single Fiber |
.10dB Typical .35dB Max Single Fiber |
.25dB Typical .75dB Max Single Fiber |
|
Return Loss |
>20dB |
>20dB |
>60dB Angle Polish |
>60dB Angle Polish |
|
|
MTP/MPO 12 Fiber Assembly Examples |
PART# |
LENGTH |
PRICE |
|
MTP Multimode 62.5, 12 Fiber Cable Assembly, Fiber Mode: Multimode 62.5/125ľm Corning Fiber Fiber Count: 12 Fiber Connector Type: 12f Standard MTP to MTP Connectors Cable Type: Oval Ribbon Orange Plenum Jacket Polish Type: UPC Flat polish Gender: MTP Male to MTP Male Length: 1 Meter
|
MT-KK600P001MCS |
1 Meter long |
$95.00 |
|
|
MTP Multimode 62.5, 12 Fiber Cable Assembly, Fiber Mode: Multimode 62.5/125ľm Corning Fiber Fiber Count: 12 Fiber Connector Type: 12f Standard MTP to MTP Connectors Cable Type: Oval Ribbon Orange Plenum Jacket Polish Type: UPC Flat polish Gender: MTP Female to MTP Female Length: 1 Meter |
MT-LL600P001MCS |
1 Meter long |
$95.00 |
|
|
MTP Multimode 62.5, 12 Fiber Cable Assembly, Fiber Mode: Multimode 62.5/125ľm Corning Fiber Fiber Count: 12 Fiber Connector Type: 12f Standard MTP to MTP Connectors Cable Type: Oval Ribbon Orange Plenum Jacket Polish Type: UPC Flat polish Gender: MTP Male to MTP Female Length: 1 Meter |
MT-KL600P001MCS |
1 Meter long |
$95.00 |
|
|
|
|
|
|
|
Connector A & B |
|
|
A |
8 Fiber MTP/APC Male (pins) |
|
B |
8 Fiber MTP/APC Female |
|
C |
8 Fiber MTP/UPC Male (pins) |
|
D |
8 Fiber MTP/UPC Female |
|
E |
12 Fiber MTP/APC Elite Male (pins) |
|
F |
12 Fiber MTP/APC Elite Female |
|
G |
12 Fiber MTP/APC Std. Male (pins) |
|
H |
12 Fiber MTP/APC Std. Female |
|
I |
12 Fiber MTP/UPC Elite Male (pins) |
|
J |
12 Fiber MTP/UPC Elite Female |
|
K |
12 Fiber MTP/UPC Std. Male (pins) |
|
L |
12 Fiber MTP/UPC Std. Female |
|
M |
24 Fiber MTP/APC Std. Male (pins) |
|
N |
24 Fiber MTP/APC Std. Female |
|
O |
24 Fiber MTP/UPC Std. Male (pins) |
|
P |
24 Fiber MTP/UPC Std. Female |
|
Q |
48 Fiber MTP/APC Std. Male (pins) |
|
R |
48 Fiber MTP/APC Std. Female |
|
S |
48 Fiber MTP/UPC Std. Male (pins) |
|
T |
48 Fiber MTP/UPC Std. Female |
|
U |
72 Fiber MTP/APC Std. Male (pins) |
|
V |
72 Fiber MTP/APC Std. Female |
|
W |
72 Fiber MTP/UPC Std. Male (pins) |
|
X |
72 Fiber MTP/UPC Std. Female |
|
|
|
|
Z |
Pigtail, No Connector |
|
Fiber Mode |
|
|
9 |
9/125 Singlemode |
|
6 |
62.5/125 Multimode |
|
7 |
50/125 Multimode 10Gb OM3 |
|
4 |
50/125 Multimode 10Gb OM4 |
|
Jacket Color |
|
|
Y |
Yellow |
|
Ř |
Orange |
|
A |
Aqua |
|
M |
Multi-Color |
|
B |
Black |
|
C |
Customer Requested |
|
Jacket Type |
|
|
R |
Riser OFNR |
|
P |
Plenum OFNP |
|
L |
Low Smoke (LSZH) |
|
V |
PVC |
|
Ř |
None |
|
C |
Customer Requested |
|
UOM Units of Measurement |
|
|
M |
Meters |
|
F |
Feet |
|
C |
Centimeters |
|
I |
Inches |
|
Fiber Count |
|
|
G |
4 Fibers |
|
E |
6 Fibers |
|
F |
8 Fibers |
|
C |
12 Fibers |
|
D |
24 Fibers |
|
J |
48 Fibers |
|
K |
72 Fibers |
|
L |
144 Fibers |
|
X |
Special, Customer Requested |
|
Pin-Out Configuration |
|
|
S |
Straight Cable, Key -Up to Key-Down, Pin1 to Pin 1 |
|
X |
Crossover Cable, Key-Up to Key Up, Pin1 to Pin 12 |
|
G |
24 Fiber MTP Pin 1 to Pin13 |
|
C |
Customer Requested, (Custom) |
|
Cable Type |
|
|
E |
3mm Round |
|
I |
3.8mm Round, (24 Fiber) |
|
R |
Bare Ribbon |
|
A |
Armored |
|
I |
Indoor / Outdoor Loose tube |
|
M |
Micro Distribution Cable |
|
S |
Special, Customer Requested. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
